OPT-2-L3006-20

OPT-2-L3006-20

Certifications:

Out of stock



ApplicationRecommended for any drive installation, specially:


  • Where local mains supply quality may be poor or unknown

  • Where high current switching loads such as large DC drives or soft starters are operating

  • Where the mains supply impedance is low

  • In remote areas prone to lightening strikes

  • Where long cables are used from the drive to the motor

Protection degreeIP20





Referencia Resumen producto Precio Cantidad
OPT-2-L3006-20

OPT-2-L3006-20
Rated voltage: 500VAC three-phase
Rated current: 6A
Inductance: 4,8mH
Dimensions: H 107 x W 95 x W 56mm
Weight:1,3kg

COP561,680
