Ref: MX4W-V-F2

Name: MX4W-V-F2
Brand: Autonics
SKU: MX4W-V-F2
Price: 756840 COP
Availability: OutOfStock

MX4W-V-F2

Out of stock

Specifications

Downloads

Power supply	24 - 240VAC/VDC 50/60Hz
Measurement type	AC or DC voltage
Voltage range	DC ±500㎷, ±200㎷, ±50㎷, ±20V, ±5V, 1-5V, ±2V, ±500V, ±200V, ±50V AC 0-500㎷, 0-200㎷, 0-50㎷, 0-20V, 0-5V, 0-2V, 0-500V, 0-200V, 0-110V, 0-50V
Display accuracy	Depends on the ambient temperature 23 ±5°C: DC ± 0.1% F. S. ± 2 dígits / AC ± 0.3% F. S. ± 3 digits 0 - 50°C: AC/DC ± 0.5% F. S. ± 3 digits
Output type	PNP open collector
Display type	LCD 4 dígits
Dimensions	H 96 x W 48 x D 24mm

Autonics - Manuales y Fichas Técnicas

Autonics_MX4W_Manual

(Size: 558 KB)

Autonics_MX4W_Manual

Referencia	Resumen producto	Precio	Cantidad
MX4W-V-F2	MX4W-V-F2 Power supply: 24 - 240VDC/VAC Type: AC/DC Voltage DC Voltage range: -500 - 500VDC (adjustable scale) AC Voltage range: 0 - 500VAC (adjustable scale) Digital outputs: 1 PNP open collector Display dimentions: H 96 x W 48mm	COP756,840
