MT4W-DV-48

MT4W-DV-48

Certifications:

Out of stock










Power supply100 - 240VAC or 12 - 24VDC (Depend of model)
Measuring typeVoltages AC or DC (Depend of model)
DC voltage range0 - 50mV | 0 - 250mV | 0 - 1V | 0 - 5V | 0 - 10V | 0 - 50V | 0 - 100V | 0 - 500V
AC voltage range0 - 1V | 0 - 2V | 0 - 10V | 0 - 20V | 0 - 50V | 0 - 110V | 0 - 250V | 0 - 500V
Output typeSPST relay | NPN OC | retransmission 4 - 20mA
Réle contact capacity3A - 250VAC
Display typeLCD 4 digits
Communication typeRS-485 Modbus RTU
DimensionsModel MT4Y (H 72 x W 36 x D 77mm)
Model MT4W (H 96 x W 48 x D 100mm)





Referencia Resumen producto Precio Cantidad
MT4W-DV-48

MT4W-DV-48
Power supply: 100 - 240VAC
Type: DC voltage
DC Voltage range: 0 - 500VDC (adjustable scale)
Digital outputs: 3 NPN OC
Communication type: RS-485 Modbus RTU
Dimensions: H 96 x W 48mm

COP685,440
