Ref: 58005

Name: Controles de temperatura digitales serie XMT
Brand: EBCHQ
SKU: 58005
Price: 147084 COP
Availability: InStock

58005

In stock

Specifications

Downloads

Power supply	85 - 240VAC
Control mode	ON-OFF, P, PID Fuzzy
RTD input type	Pt100, Cu 50
TC input type	K, J, S, E, B, N, W, Re
Sampling period	500ms
Contact capacity	7A a 250VAC / 10A a 30VDC
Size	H 48 x W 96 x D 110 mm H 72 x W 72 x D 110 mm H 48 x W 48 x D 110 mm H 96 x W 96 x D 110 mm

EBCHQ - Manuales y Fichas Técnicas

Ebchq - 580xx - Manual

(Size: 1 MB)

Referencia	Resumen producto	Precio	Cantidad
58005	XMTE-818 Control type: ON-OFF, proportional, PID Fuzzy Power supply: 85 - 240VAC Temperature inputs: 1 thermocouple or 1 RTD Thermocouple type: Type K, J, S, E RTD type: Pt100, Cu50 Control outputs: 1 SPDT relay Auxiliar digital outputs: 1 SPST relay Dimensions: H 96 x W 48mm	COP147,084
